Electrical Specifications

Frequency Bands:

1710-2700MHz

Gain (Max):

11dBi

VSWR:

<2:1

Feed Power Handling:

10W

Input Impedance:

50Ohm (nominal)

Polarisation:

+45°and-45°

Port to Port Isolation:

>15dBDC

MIMO decorrelation:

< 0.3

Cable loss:

0.35dB/m @900 MHz

0.53dB/m @ 2000 MHz

0.6dB/m @2500 MHz

DC Short:

Yes

Mechanical Specifications

Product Dimensions (L x W x D):

300 mm x 145 mm x 57 mm

Packaged Dimensions:

360 mm x 160 mm x 115 mm

Weight:

1,35 kg

Packaged Weight:

1,60 kg

Radome Material:

ABS (Halogen Free)

Radome Colour:

Pantone - Cool Gray (1C)

RAL - 7047

Environmental Specifications

Wind Survival:

<120 km/h

Temperature Range (Operating):

-40°C / +70°C

Environmental Conditions:

Outdoor/Indoor

Operating Relative Humidity:

Up to 98%

Storage Humidity:

5% to 95% - non condensing

Storage Temperature:

-40°C / +70°C

Certification Approvals and Standards

Flammability rating:

UL 94-V0

EN 13823

Water Ingress Protection Ratio/Standard:

IP 65 (NEMA 4X)

Impact resistance:

IK 08

Salt Spray:

MIL-STD 810F/ASTM B117

Product Safety:

Complies with UL, CE, EN, CSA and IEC standards
