IES2016-16T-P220
16*10/100Base-T(X), RJ45, power supply 220VAC (100~240VAC)
IES2016-16T serisi, 16 port 100M unmanaged industrial Ethernet switch modellerinden oluşur. Seri 2 farklı ürün sunar ve 100M copper port desteği sağlar. Power supply seçenekleri olarak 220VAC ve 12~48VDC desteklenir. DIN-Rail veya wall mounting ile kurulabilir, böylece farklı uygulama senaryolarına uyum sağlar.
- 16 x 100M copper port destekler
- Opsiyonel AC/DC power supply ve DC dual power supply redundancy
- Giriş voltajı: 12~48VDC veya 100~240VAC
- -40~75°C geniş çalışma sıcaklık aralığı destekler
DIP switch, flow control ve storm suppression fonksiyonlarını aktif edebilir. Donanım fanless yapıdadır, düşük güç tüketir ve zorlu EMC gereksinimlerine uygun olduğunu gösteren sıkı endüstriyel testlerden geçmiştir. Raylı sistemler, akıllı şehir uygulamaları, güvenli şehir çözümleri, yenilenebilir enerji sistemleri, akıllı üretim ve diğer endüstriyel sahalarda yaygın şekilde kullanılabilir.
| Model | Açıklama |
|---|---|
| IES2016-16T-2P48 | Unmanaged, 16*10/100Base-T(X), RJ45 , dual power supply 12/24/48VDC, non-polarity, DIN-Rail or wall mounting, -40~75℃ operating temperature |
| IES2016-16T-P220 | Unmanaged, 16*10/100Base-T(X), RJ45, power supply 220VAC (100~240VAC), DIN-Rail or wall mounting, -40~75℃ operating temperature |
Standard & Protocol
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3x for flow control
Interface
Copper port: 10/100Base-T(X), RJ45, Full/Half Duplex Mode, MDI/MDI-X Autotunning
LED Indicator
Running Indicator, Power Supply Indicator, Port Indicator, Alarm Indicator (Reserved)
Switch Property
Transmission mode: store and forward
MAC address: 8K
Backplane bandwidth: 3.2G
Switch time delay: <10μs
Power Requirement
This series product has two optional power supply solutions:
Solution 1
Power supply range: 12~48VDC
Connection method: 4-pin 5.08mm pitch terminal blocks
Power supply quantity: dual power supply redundancy backup
Connection protection: non-polarity
Over-current protection: 3A
Solution 2
Power supply input: 220VAC (100~240VAC)
Connection method: 4-pin 5.08mm pitch terminal blocks (power supply occupies 2 pins)
Over-current protection: 2A
Power Consumption
IES2016-16T-P220
No-load(@220VAC): 0.7W
Full-load(@220VAC): 2.6W
Environmental Limit
Operating temperature range: -40~75℃
Storage temperature range: -40~85℃
Relative humidity: 5%～95% (no condensation)
Physical Characteristic
Housing: IP40 protection, metal
Installation: DIN-Rail mounting or wall mounting
Dimension (W x H x D): 53mm×138mm×110mm
Industrial Standard
IEC 61000-4-2 (ESD, Electro-Static discharge), Level 4
Air discharge: ±15kV
Contact discharge: ±8kV
IEC 61000-4-4 (EFT, Electrical Fast Transients), Level 3
Power supply: ±2kV
Ethernet port: ±1kV
IEC 61000-4-5 (Surge), Level 4
Power supply: common mode±4kV, differential mode±2kV
Ethernet port: common mode±4kV, differential mode±2kV
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Certification
CE, FCC, RoHS
