ioLogik E2210
Smart Ethernet Remote I/O with 12 DIs, 8 DOs
- Patentli Active OPC Server özelliği ile aktif iletişim.I/O cihazı doğrudan verileri Active OPC sunucuya gönderir.
- E-mail, SNMP Trap, TCP, UDP yöntemleri ile akıllı alarm sistemi
- SNMPv1/v2c/v3 protokol dessteği
- Peer-to-peer iletişim mimarisi, uzak noktadaki DI girdilerini merkezdeki I/O ünitesinin DO çıkışlarına atamak çok kolay
- Patentli Click&Go control logic ile IF-THE-ELSE temelli kurallar eklemek çok kolay. 24 kurala kadar destekler
- Kullanıcı dostu Web arabirimi ile de konfigürasyon opsiyonu
ÜRÜN SİPARİŞ KODLARI :
| Model | Açıklama |
|---|---|
| ioLogik E2210 | Active Ethernet I/O with 12 digital inputs and 8 digital outputs, -10 to 60°C operating temperature |
| ioLogik E2210-T | Active Ethernet I/O with 12 digital inputs and 8 digital outputs, -40 to 75°C operating temperature |
| ioLogik E2212 | Ethernet Micro RTU Controller with 8 digital inputs, 8 digital outputs, and 4 configurable DIOs, -10 to 60°C operating temperature |
| ioLogik E2212-T | Ethernet Micro RTU Controller with 8 digital inputs, 8 digital outputs, and 4 configurable DIOs, -40 to 75°C operating temperature |
| ioLogik E2214 | Ethernet Micro RTU Controller with 6 digital inputs and 6 relay outputs, -10 to 60°C operating temperature |
| ioLogik E2214-T | Ethernet Micro RTU Controller with 6 digital inputs and 6 relay outputs, -40 to 75°C operating temperature |
| ioLogik E2240 | Ethernet Micro RTU Controller with 8 analog inputs and 2 analog outputs, -10 to 60°C operating temperature |
| ioLogik E2240-T | Ethernet Micro RTU Controller with 8 analog inputs and 2 analog outputs, -40 to 75°C operating temperature |
| ioLogik E2242 | Ethernet Micro RTU Controller with 4 analog inputs and 12 configurable DIOs, -10 to 60°C operating temperature |
| ioLogik E2242-T | Ethernet Micro RTU Controller with 4 analog inputs and 12 configurable DIOs, -40 to 75°C operating temperature |
| ioLogik E2260 | Ethernet Micro RTU Controller with 6 RTD inputs and 4 digital outputs, -10 to 60°C operating temperature |
| ioLogik E2260-T | Ethernet Micro RTU Controller with 6 RTD inputs and 4 digital outputs, -40 to 75°C operating temperature |
| ioLogik E2262 | Ethernet Micro RTU Controller with 8 thermocouple inputs and 4 digital outputs, -10 to 60°C operating temperature |
| ioLogik E2262-T | Ethernet Micro RTU Controller with 8 thermocouple inputs and 4 digital outputs, -40 to 75°C operating temperature |
| • Inputs and Outputs | |
| Digital Inputs | 12 channels |
| Digital Outputs | 8 channels |
| Isolation | 3k VDC or 2k Vrms |
| • Digital Input | |
| Sensor Type | Wet Contact (NPN), Dry Contact |
| I/O Mode | DI or Event Counter |
| Dry Contact | • On: short to GND • Off: open |
| Wet Contact (DI to GND) | • On: 0 to 3 VDC • Off: 10 to 30 VDC |
| Common Type | 12 points per COM |
| Counter Frequency | 900 Hz |
| Digital Filtering Time Interval | Software Configurable |
| • Digital Output | |
| Type | Sink |
| I/O Mode | DO or Pulse Output |
| Pulse Output Frequency | 1 kHz |
| Over-Voltage Protection | 45 VDC |
| Over-Current Protection | 2.6 A (4 channels @ 650 mA) |
| Over-Temperature Shutdown | 175°C (min.) |
| Current Rating | 200 mA per channel |
| • Power Requirements | |
| Input Voltage | 12 to 36 VDC |
| Input Current | 190 mA @ 24 VDC |
| • MTBF (mean time between failures) | |
| Time | 213,673 hrs |
| Standard | Telcordia SR332 |
| • Common Specifications | |
| • LAN | |
| Ethernet | 1 10/100 Mbps RJ45 port |
| Protection | 1.5 kV magnetic isolation |
| Protocols | Modbus/TCP (slave), TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP |
| • Serial | |
| Interface | 1 RS-485-2w terminal block port |
| Parity | None |
| Data Bits | 8 |
| Stop Bits | 1 |
| Flow Control | None |
| Baudrate | 1200 to 115200 bps |
| Protocols | Modbus RTU (gateway) |
| • Physical Characteristics | |
| Wiring | I/O cable max. 14 AWG |
| Dimensions | 115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in) |
| Weight | under 250 g (0.55 lb) |
| Mounting | DIN-rail or wall |
| • Environmental Limits | |
| Operating Temperature | Standard Models: -10 to 60°C (14 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Shock | IEC 60068-2-27 |
| Vibration | IEC 60068-2-6 |
| Altitude | Up to 2000 m |
| Note | Please contact Moxa if you require products guaranteed to function properly at higher altitudes. |
| • Standards and Certifications | |
| Safety | UL 508 |
| EMC | EN 61000-6-2/6-4 |
| EMI | CISPR 22, FCC Part 15B Class A |
| EMS | IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m 1.4 GHz to 2 GHz: 3 V/m 2 GHz to 2.7 GHz: 1 V/m IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV IEC 61000-4-5 Surge: Power: 1 kV IEC 61000-4-6 CS: 10 V IEC 61000- |
| Green Product | RoHS, CRoHS, WEEE |
| Note | Please check Moxa’s website for the most up-to-date certification status. |
| • Warranty | |
| Warranty Period | 5 years |
