TLC422/9
Port-powered RS-232 to RS-422 Converter
RS-232 to RS-422 converter, 15KV ESD protection, DB9
- 1x RS-232 seri port ile 1x RS-422 seri port arasında çift yönlü veri aktarımı
- Harici güç kaynağı gerektirmez
- Otomatik seri port sinyal hızı algılama (0 ~ 115200bps)
- Veri iletim yönünü otomatik algılayarak veri akışını kontrol eder
| ÜRÜN | RS-232(DB9) | RS-232(DB25) | RS-422(DB9) | RS-422(DB25) |
| TLC422/9 | 1 | - | 1 | - |
| TLC422/25 | - | 1 | - | 1 |
| Serial Port |
Standard: EIA RS-232C, RS-422 Serial port quantity: 1 RS-232 serial port, 1 RS-422 serial port Baud rate: 0~115200bps RS-232 signal: TXD, RXD, GND RS-422 signal: T+, T-, GND, R+, R- Interface type: RS-232 serial port, adopts DB9 or DB25, Female； RS-422 serial port, adopts DB9 (equipped with 5-pin terminal blocks) or DB25M Transmission distance: RS-232 serial port, 15m； RS-422 serial port, 1200m Interface protection: 15KV electrostatic protection
|
|
Power Requirement
|
No external power supply required Obtain power from TXD, RTS, DTR signals of RS-232 serial port
|
|
Power Consumption |
Static power consumption: ≤10mA Dynamic power consumption(mean): ≤40mA
|
|
Environmental Limit |
Operating temperature: -20~60℃ Storage temperature: -25~85℃ Relative humidity: 5%～95%(no condensation)
|
|
Physical Characteristic |
Housing: plastic Dimension (W x H x D): 90mm×33mm×16.5mm(DB9，with terminal blocks) 65mm×55mm×16.5mm(DB25) Weight: 40g
|
|
Certification |
CE, FCC, RoHS |
